SmartArt builds a top-down org chart in a few clicks, as long as the structure is a simple hierarchy. Operations and finance teams at private equity and fund management firms usually need two kinds of charts: a personnel org chart and a legal entity structure chart showing fund LPs, GP LLCs, management companies, and SPVs. SmartArt was built for the first. The second pushes past what SmartArt can draw.
This guide covers both paths, plus the point where PowerPoint stops being the right tool for a 50-plus-entity portfolio. It applies to supported PowerPoint versions.
Build the base chart with SmartArt
SmartArt's Hierarchy category is Microsoft's built-in method for a personnel chart, and it needs nothing beyond a standard Microsoft 365 subscription. It is the tool to reach for when a reorg lands and the chart needs rebuilding.
Insert the graphic
Start from the layout that matches how the chart will be read, then add names. On the Insert tab, in the Illustrations group, click SmartArt. In the Choose a SmartArt Graphic gallery, click Hierarchy, select the Organization Chart layout, and click OK. Type directly in a box, or open the Text pane from the control on the SmartArt border and type over each [Text] placeholder. For headshots, Microsoft's SmartArt guidance points to Picture Organization Chart, which supports assistant and hanging layouts, or Circle Picture Hierarchy; each box carries a picture icon for inserting an image file.
Add boxes
The Text pane is usually quickest: put the cursor at the end of a line, press Enter, and type. For placement control, click the existing box closest to where the new box belongs, then under SmartArt Tools > Design > Create Graphic, click the arrow under Add Shape and pick one of five options.
Add Shape After or Add Shape Before: inserts a box at the same level as the selected box
Add Shape Above: inserts a box one level up; the selected box and its subordinates each drop one level
Add Shape Below: inserts a subordinate box
Add Assistant: adds an assistant box above other boxes at the same level; assistant availability is limited to the Organization Chart, Name and Title Organization Chart, and Picture Organization Chart layouts
In the Text pane, an assistant shape shows as a bullet with a line attached, and it appears after its siblings even though it sits above them on the slide.
Apply a hanging layout
Click the box one level above the subordinates you want to rearrange, then under SmartArt Tools > Design > Create Graphic, click Layout. Standard centers subordinates below the box, Both arrange them two per row, and Left Hanging or Right Hanging stack them vertically, with the parent box sitting to the right (Left Hanging) or left (Right Hanging) of the stack. SmartArt cannot automatically connect two top-level boxes; the workaround is to add a box at the top level and draw the line manually via Insert > Illustrations > Shapes.
Rearrange boxes as the structure changes
Restructuring is most reliable in the Text pane; users report that SmartArt auto-layout fights attempts to drag boxes on the slide.
Promote, demote, and move branches
A single hire moving under a new principal should not mean redrawing the branch. Press Tab in the Text pane to demote a line and Shift+Tab to promote it; the keyboard shortcuts Alt+Shift+Left/Right Arrow do the same for selected text, and Alt+Shift+Up/Down Arrow reorders it.
To move a branch, click its second-level root in the Text pane and use Move Up or Move Down; the whole branch travels together. To delete a box, click its border and press Delete. PowerPoint's top-level deletion behavior promotes the assistant to the top when you delete a top-level shape with subordinates and an assistant.
Mark dotted-line relationships
Right-click the connector between two boxes, click Format Shape, choose Line or Line Style, and select a Dash type. PMI's matrix structure analysis notes that solid- and dotted-line relationships carry different meanings depending on local management custom, so define your conventions in a legend on the chart itself. You cannot delete a connecting line in SmartArt; lines are part of the shapes they connect, so hide one with Shape Outline > No Outline on the Format tab.
Format the chart or convert it to shapes
A chart that must match brand styling or size one SPV box differently outgrows SmartArt's one-click formatting.
Colors, styles, and resets
Branding starts with Change Colors and the SmartArt Styles gallery under SmartArt Tools > Design, where one style bundles line, bevel, shadow, and fill effects. To recolor a single box, right-click its border, choose Format Shape, and set a solid fill.
Convert to shapes when SmartArt fights you
With no automatic link between two top-level boxes and no one-to-multiple or multiple-to-one branching, SmartArt cannot draw matrix or multi-parent structures. The documented escape hatch is Convert to Shapes: click the graphic, then SmartArt Tools > Design > Convert > Convert to Shapes, or press Ctrl+Shift+G twice.
The conversion is permanent once the file is closed; the SmartArt Tools tabs disappear, and the shapes cannot be regrouped back into SmartArt. In exchange you get full control over sizing and placement, plus some animation effects unavailable to SmartArt. After converting, join boxes with connectors rather than plain lines, since connectors stay attached to a moved shape.
Draw complex entity structures manually
A fund structure where the same principals own the GP LLC and the management company at different percentages cannot be drawn in a single SmartArt hierarchy. Manual shapes and connectors are the answer, at the cost of setup time.
PowerPoint provides three connector types under Insert > Shapes > Lines: straight, elbow, and curved. Elbow connectors produce the right-angle bends expected in formal charts. Rest your pointer over a shape to reveal connection dots, then drag from one dot to another; right-click a connector in the gallery and choose Lock Drawing Mode to draw the same connector repeatedly. Precision comes from the arrangement tools.
Alignment and distribution tools under Shape Format > Align offer align left/center/right, top/middle/bottom, and distribute commands (distribution requires three or more selected shapes)
Grid and snap settings under View > Gridlines plus "Snap objects to grid" keep boxes on a consistent grid; hold ALT while dragging to override the snap temporarily
Smart Guides, the red dashed lines that appear while dragging, signal alignment and equal spacing
Group aligned shapes afterward so branches move without losing their relative positions
Save the finished layout as a template slide so the next fund vehicle starts from a formatted base.
Know where PowerPoint hits its limits
Once a structure outgrows a single readable slide, PowerPoint may hide information instead of displaying the full chart.
Slide space and shape limits
Slides max out at 56 inches in either direction with no override. When a SmartArt layout's shape limit is exceeded, SmartArt hides the excess rather than flagging it: a red X replaces the bullet in the Text pane, and if you keep and close the same layout, the information is not saved. In a Microsoft support forum exchange, a user building a chart for roughly 1,200 members saw only partial records rendered; Microsoft support recommended Visio for large data imports.
No data link, and the Visio gap widened
PowerPoint has no data-link or refresh mechanism, so structural changes require hand-editing shapes and connectors. The Visio Data Visualizer add-in for Excel, previously a no-extra-license path from a data table to a diagram, was retired on March 2, 2026, when the cloud service powering it was shut down; embedded diagrams built with it no longer render or refresh. Data-driven org charts remain available in Visio Plan 1 and Plan 2: Plan 1 runs $5 per user per month billed annually and is web-app only, while Plan 2 runs $15 per user per month billed annually and adds two-way Excel data sync in the desktop app.
Monthly billing without an annual commitment costs more on both plans. Even with a paid plan, Visio's Organization Chart Wizard keeps no link to its data source, and regenerating a chart discards themes and photos. Copilot can generate or edit SmartArt content with a Microsoft 365 Copilot license, but no Microsoft source confirms it can build an org chart from a natural-language prompt.
Regulatory stakes for entity charts
Three regulatory sources illustrate the data an entity chart may need to show, and each involves data that must be re-keyed by hand every time a static slide changes.
The Federal Reserve's FR Y-6 instructions call for full legal names, Legal Entity Identifiers where the entity has one, physical addresses, and state or country of incorporation for each entity
FinCEN's Customer Due Diligence Rule requires beneficial owners to be identified directly or indirectly through multiple corporate structures
The SEC's Form ADV Part 1A appendix asks for ownership in coded ranges, with a separate schedule for direct owners and one for indirect owners
Design conventions for fund entity charts
Fund entity charts read fastest when the controlling entity sits on top and no connectors cross.
Use a top-down layout with the controlling entity or principals at the top; comprehension research has found that crossing connectors is one of the most disruptive factors for reading speed and accuracy, so route lines to avoid crossings
Draw the GP and the management company as separate boxes; the two are typically kept distinct so operational obligations like office leases sit apart from the fund's investment assets, and they connect through a management agreement
Show ownership percentages per entity; splits frequently differ entity by entity, so copying one percentage across every box is often wrong
Label connecting arrows for cash flows (management fees from the fund LP to the management company, carried interest to the GP) and contractual relationships
Color-code boxes by entity type; above 50 entities, split by fund or subsidiary group across slides tied to a master overview slide
Keep your fund entities compliant with Discern
Building the chart is only half the job. A PowerPoint chart, hand-drawn or converted from SmartArt, shows structure at a single point in time; it cannot tell you whether any box on it is current on annual reports, covered by a registered agent, or still in good standing with the Secretary of State.
Discern's entity management system acts as your system of record instead: updates to entity information are automatically saved for future filings and dynamically reflected in SOS annual reports, formation filings, foreign registration filings, and the org chart, with custom labels, entity grouping, and general partner chain tracking for LP and fund structures. The chart is rendered directly from that same entity database, so a formation or dissolution recorded in the system appears in the chart without a separate synchronization step.
For firms running fund LPs, GP LLCs, management companies, and SPVs across multiple vintages, this matters most at scale. Discern provides registered agent coverage across all 51 jurisdictions, handles foreign registration filings, and supports segregated payment management across hundreds of bank accounts, so a portfolio spanning dozens of entities and jurisdictions can be tracked, and charted, from a single system of record.
Book a demo with Discern to see how quickly your entity records can become an org chart that stays current.
This article provides general compliance information and does not constitute legal advice. Consult qualified legal counsel for guidance specific to your situation.
Frequently asked questions
A few questions come up often when finance and operations teams start building or maintaining a fund entity chart.
What's the difference between a personnel org chart and a legal entity structure chart?
A personnel org chart shows reporting lines between people. A legal entity structure chart shows ownership and control relationships between legal entities, such as a fund LP, its GP LLC, a management company, and any SPVs underneath. SmartArt's Hierarchy layouts are built for the first kind and only stretch to cover the second when the structure stays simple.
Can SmartArt draw a fund structure where the same principals own the GP and the management company at different percentages?
No. SmartArt cannot automatically connect two top-level boxes and does not support one-to-multiple or multiple-to-one branching, so it cannot draw matrix or multi-parent ownership. Converting the SmartArt graphic to shapes, or building the chart manually with connectors, is the workaround.
What happens when a chart has more entities than SmartArt can display?
SmartArt hides the excess rather than warning you: a red X appears in the Text pane in place of the missing bullet, and if you save and close the file, that data is not recovered later. Slides also max out at 56 inches in either direction. Once a portfolio passes roughly 50 entities, splitting the chart across multiple slides, or moving to a data-driven tool, becomes the more reliable option.
How do I keep a fund entity chart accurate as the portfolio changes?
A slide only reflects the structure as of the day someone last updated it. Keeping the underlying entity records (ownership percentages, general partner relationships, good standing, registered agent coverage) current in a system of record, rather than only on the slide, is what keeps the chart from going stale between redraws.
