A corporate structure chart is a hierarchical diagram of the legal entities in a corporate group: companies, subsidiaries, and affiliates, the jurisdiction where each is formed, its entity type, and the percentage of ownership or control held by other entities or individuals. It answers a different question than the org chart on your intranet. The org chart shows who reports to whom; the structure chart shows who owns what, and it is a document a buyer's counsel or a lender will commonly request by name.
For venture capital firms, the directly managed footprint is generally limited to the fund LP, GP LLC, management company, and SPVs, commonly about 4 to 12 entities per fund. Private equity firms and larger fund managers can have much larger structures: a firm running three fund vintages with SPVs and feeder vehicles can hold 50 to 200+ entities across multiple jurisdictions, and each entity carries its own Secretary of State registration, annual report deadline, registered agent requirement, and tax filing obligations.
What a corporate structure chart shows
The reporting regime that applies to your organization determines the required disclosures, but federal forms illustrate the core fields commonly tracked in an entity chart: legal name, entity type, jurisdiction, address, and ownership or control percentages.
The Federal Reserve's FR Y-6 report requires covered bank holding companies to disclose each entity's full legal name, legal address, intercompany ownership and control relationships, and the percentage of voting and nonvoting equity held by each direct holder.
SEC Regulation S-K Item 601(b)(21) requires public registrants to list all subsidiaries in Exhibit 21, with each subsidiary's state or jurisdiction of incorporation and the names under which it does business. The rule includes exceptions: names of subsidiaries that, in the aggregate, wouldn't constitute a significant subsidiary may be omitted, so Exhibit 21 doesn't necessarily list every entity in a large group.
IRS Form 851, the Affiliations Schedule (current version dated October 2016), discloses voting stock percentages among members of a consolidated group, which 26 U.S.C. §1504(a)(2) defines through a common parent owning at least 80% of voting power and 80% of total value of another includible corporation.
Structurally, entity charts break the rules HR charts follow. Depending on governing law and the ownership structure, an entity can have multiple parents and subsidiaries, ownership lines can skip generations, and in some structures a subsidiary can hold an interest in its own parent. Even a wholly owned subsidiary generally remains a legally independent entity with its own management and corporate bodies, and a well-drawn chart reflects that separation.
Entity types and how they appear on the chart
Each node carries its own tax treatment and ownership notation, and that is what a lender or buyer reads off your chart first.
Entity type | Tax treatment | Chart notation |
|---|---|---|
C-corporation | Generally subject to a flat 21% federal corporate rate; dividends taxed again at the shareholder level. State and local corporate taxes may also apply. | "Inc." or "Corp." with percentage of voting and total stock |
S-corporation | Generally pass-through. Under IRC §1361(b)(1)(A) and (D), limited to 100 shareholders and one class of stock, along with other eligibility rules in §1361(b) (permitted shareholder types, no nonresident-alien shareholders). | Like a C-corp, plus shareholder-eligibility notes; wholly owned QSubs marked as disregarded |
LLC | Under IRS Publication 3402, a domestic multi-member LLC defaults to partnership classification and a single-member LLC defaults to disregarded-entity treatment (subject to employment-tax and excise-tax qualifications); either can elect corporate taxation on Form 8832 (a separate election on Form 2553 is required for S-corp status). | "LLC" with membership interest percentages and manager or managing member designations |
Limited partnership (LP) | Partnership taxation by default. A general partner that is an individual or other non-limited-liability entity bears unlimited liability; limited partners' exposure is typically capped at their contribution. (In practice, the GP role is often filled by an LLC, which changes the practical liability picture.) | GP node (commonly an LLC) above, LP investors below, with percentage or commitment labels |
Delaware dominates this population: the Delaware Division of Corporations reports more than 2.28 million registered entities as of its 2025 annual report, with LLCs making up the large majority of that total.
How PE and VC fund structures chart out
A single fund is typically three or four entities, not one, and the chart multiplies with every vintage.
The core triad
Three entities do the work in almost every fund:
The Fund LP is commonly a Delaware limited partnership: LPs commit capital into it, portfolio investments sit inside it, and distributions flow out of it under the Limited Partnership Agreement. An NBER working paper (No. 17568, 2011) on private equity fund structure notes that these partnerships usually last around ten years, with the firm serving as general partner and investors as limited partners.
The GP is often organized as an LLC because an individual or non-limited-liability general partner bears unlimited liability, so the individuals behind it keep limited liability. The GP typically commits around 1% of fund capital and receives carried interest, commonly cited as around 20% of profits, though terms vary by fund.
The management company LLC employs the investment professionals, holds the office lease and trademarks, and collects the management fee (commonly cited in the 2% to 2.5% range on committed capital, often declining after the investment period, though this varies by strategy, fund size, and commitment base). The management company is typically "the continuing business" across fund vintages.
Multi-fund firms add a GP per vintage
Firms running multiple vintages typically create a new GP LLC for each fund so one fund's legal or financial issues do not spill into the others. On the chart, that commonly means one management company at the top, fund-specific GP LLCs below it, and each GP connected to its own Fund LP.
Delaware is a common choice of jurisdiction for these vehicles: the Delaware Revised Uniform Limited Partnership Act and the Delaware LLC Act allow GPs to modify fiduciary duties by contract, and the Court of Chancery has a body of precedent that fund sponsors often cite as a reason for choosing Delaware.
Delaware's alternative-entity tax and franchise tax rules are specific to entity type and activity; confirm current treatment for a given LP or LLC directly with the Division of Corporations or tax counsel rather than assuming a blanket exemption.
SPVs, feeders, and blockers
Advisers to pooled investment vehicles commonly use investment-specific SPVs to hold individual investments; the degree of adviser control and the reasons for using them vary by fund and deal. Mixed investor bases add more nodes: a Delaware feeder for U.S. taxable investors who need Schedule K-1 treatment, a Cayman feeder for U.S. tax-exempt and non-U.S. investors, and, in some structures, a blocker corporation that elects corporate taxation and pays corporate tax on UBTI before distributing proceeds, which is one common way sponsors manage UBTI exposure for tax-exempt investors such as pension funds and endowments. The specific tax outcome depends on entity classification, income type, leverage, and distribution mechanics, so this is illustrative rather than a universal rule.
What real corporate stacks look like
Public filings show how layered these structures get, and how many nodes your own chart may need.
A PE buyout commonly uses a tiered acquisition structure with layers sometimes called Topco, Midco, and Bidco, though the exact instrument placement (equity, subordinated debt, senior acquisition debt) is transaction-specific and not universal.
Google's 2015 holding company reorganization was documented in Form 8-K filings, including a Form 8-K12B dated October 2, 2015, and made Google a wholly owned subsidiary of the newly formed Alphabet Inc.
Berkshire Hathaway's Exhibit 21 shows a holding company inside a holding company: Berkshire Hathaway Energy Company, itself a Berkshire subsidiary, has PacifiCorp, MidAmerican Energy Company, and NV Energy within its subsidiary chain (some held indirectly through intermediate entities).
Why the chart matters for M&A, lenders, and compliance
Buyers' counsel and lenders commonly ask for a current entity chart as part of diligence, and diligence lists routinely pair it with certificates of good standing from each jurisdiction.
M&A due diligence
An organizational chart of the company and its subsidiaries is a standard item on many M&A due diligence checklists, often alongside current officer and director information for each subsidiary, though exact requirements vary by transaction.
Published request lists also commonly ask for certificates of good standing from each jurisdiction, prior years' annual reports and active status reports, and organizational documents for material subsidiaries. Gaps in your minute books or missing filings can signal governance problems that create ownership disputes or officer authority questions at closing.
Credit agreements
Lenders frequently make subsidiary structure a closing representation in credit agreements, often requiring a schedule listing each subsidiary's legal name, jurisdiction of organization, and percentage ownership
Equinix, Cheniere Energy, and Cleveland-Cliffs are examples of public filers whose credit agreement exhibits include subsidiary-related schedules of this kind; the precise wording of any given representation should be confirmed against the actual filed exhibit rather than assumed from another company's agreement.
State compliance and beneficial ownership
In many states, an entity on your chart that transacts business outside its formation state may need to qualify as a foreign entity and appoint a registered agent, depending on the destination state's statute and the nature of the entity's activities there; annual report obligations vary by state and entity type.
For the 2026 Florida filing year, Florida imposes a $400 late fee (not applicable to nonprofit corporations) if the Florida annual report is not filed by May 1, and an entity that still hasn't filed by the third Friday of September is administratively dissolved or revoked at the close of business on the fourth Friday of September. The consequences can extend to litigation: the Mississippi Supreme Court affirmed dismissal of a lawsuit brought by a corporation that had been administratively dissolved for failing to file an annual report while the suit was pending (Wayne Johnson Electric Inc. v. Robinson Electric Supply Company, Inc., 266 So.3d 643 (Miss. 2019)), holding that a dissolved corporation could not maintain the action.
On the federal side, a Federal Register final rule permanently exempts U.S. companies and U.S. persons from beneficial ownership information reporting, effective August 14, 2026, and FinCEN has stated it will delete beneficial ownership data previously reported by U.S. persons who are now exempt. Under the final rule, "reporting company" is limited to entities formed under the law of a foreign country that have registered to do business in a U.S. state or Tribal jurisdiction; those foreign reporting companies must still report beneficial ownership information for their non-U.S.-person beneficial owners.
That math still requires the chart: FinCEN's compliance guidance has illustrated indirect ownership using examples such as a 25% owner of a company that owns 50% of a reporting company being treated as a 12.5% indirect owner; confirm the current version and applicability of that guidance under the 2026 rule before relying on the exact percentages.
Templates and tools for building the chart in 2026
Mainstream diagramming tools generally don't ship a dedicated, out-of-the-box legal entity chart template; a Microsoft Q&A community response reported that the responder hadn't identified one built into Visio, where the built-in org chart templates are people-oriented rather than ownership-oriented. The practical options:
Microsoft Visio: Visio Plan 2 is listed at $15/user/month on an annual commitment and links shapes to live data in Excel, SharePoint lists, and SQL Server.
Lucidchart: imports CSV, Google Sheets, or Excel to auto-generate charts.
draw.io: free; it supports importing Visio VSDX files (export fidelity and native-format support should be checked for your use case), and its AI-assisted diagram generation feature predates 2026 and received an update in August 2026.
Ownership-percentage labels and jurisdiction tags require custom configuration in every tool reviewed, so build your template around the per-node fields in the next section.
Keeping the chart accurate
A chart is only as reliable as the entity data behind it, and many legal departments say that data is a problem. A 2021 report from EY Law and the Harvard Law School Center on the Legal Profession found that 89% of organizations surveyed reported challenges with legal entity management and that 68% lacked access to accurate, up-to-date entity information.
Fields every node needs
Each node on your chart needs, at minimum:
Entity name
Entity type
Jurisdiction
Ownership or economic interest percentages, with the denominator and ownership type (voting, economic, profits interest, fully diluted) labeled, since voting ownership, profits interests, options, and commitments don't always sum to a clean 100% on a single chart
EIN
Good standing status
Assign a clear owner for keeping the chart current, centralize entity data in a single repository, and automate deadline alerts. (Titled-officer requirements, including whether a corporate secretary is required, vary by state and entity type, so confirm your state's specific statute rather than assuming a universal rule.)
The cost of carrying extra entities
Estimates for annual carrying costs per legal entity vary by source and by entity complexity; some advisers cite figures reaching up to $50,000 for a complex entity, which is part of the arithmetic behind legal entity rationalization.
Keep every entity in good standing with Discern
Drawing the chart is the easier half of the job. Keeping every node on it registered, filed, and in good standing across dozens of jurisdictions is ongoing work, and that is the Secretary of State layer Discern manages: Discern's registered agent services, Discern's annual report filing support, and Discern's foreign registration services.
For PE firms and fund managers running entities across multiple funds and vintages, Discern pre-fills forms with your entity information, lets you manage compliance from a single dashboard, tracks deadlines automatically, and files across states in parallel. For Delaware LP and LLC fund entities, Discern automates franchise tax calculation and filing.
Book a demo with Discern to see how Discern manages multi-state compliance for every entity on your chart.
This article provides general compliance information and does not constitute legal advice. Consult qualified legal counsel for guidance specific to your situation.
Frequently asked questions
Here are answers to a few questions that come up often when teams start building or maintaining a corporate structure chart.
How is a corporate structure chart different from an org chart?
An org chart shows reporting lines between people and roles. A corporate structure chart shows legal ownership and control between entities: which company owns what percentage of which subsidiary, and in which jurisdiction each is formed. Buyers, lenders, and regulators generally request the entity chart, not the org chart, since it's the document that answers who legally controls what.
Who typically asks to see a corporate structure chart?
Buyer's counsel and lenders commonly request one during diligence, often alongside certificates of good standing for each jurisdiction. Regulators may request one depending on the reporting regime that applies to your organization (for example, bank holding companies filing the FR Y-6, or public companies disclosing Exhibit 21).
Does every entity on the chart need to file its own annual report?
In most states, yes, though requirements and deadlines vary by state and entity type, and some states (like Delaware for LLCs and LPs) require an annual tax payment rather than a filed annual report. Confirm the specific requirement for each entity's formation state and, if it operates elsewhere, any state where it's registered as a foreign entity.
What happens if an entity on the chart falls out of good standing?
Consequences vary by state but commonly include late fees, loss of the ability to bring or maintain lawsuits, and eventually administrative dissolution or revocation. Reinstatement is usually possible but requires filing past-due reports and paying accumulated fees and penalties, and the entity may lose access to financing or deal-closing certificates in the meantime.
